Frequently Asked Questions
What is the maximum handling capacity of the WP-40 robot?
The WP-40 collaborative robot can handle a maximum load of 30kg, which includes the weight of the gripper or end-of-arm tooling.
How fast can the workstation palletize boxes?
The system offers a palletizing speed of approximately 8 to 12 boxes per minute, depending on the box dimensions and layout requirements.
What are the pallet dimension requirements?
The standard setup is designed for pallets with a length of 1200mm, width of 1200mm, and a height of 150mm.
Does the system require a specific power supply?
Yes, the workstation requires an AC380V, 50Hz power supply, with a control voltage of DC 24V and a total power consumption of 4kw.
What is the maximum stacking height achievable?
The robot can achieve a palletizing height of up to 2000mm, supported by a 600mm lifting column for extended reach.
Is the robot easy for operators to use?
Absolutely. The WP-40 is designed for simple operation, allowing for manual pallet placement and an intuitive control interface for warehouse staff.
