Gantry Robot for Warehouse Picking Operation with International Certification and Modular Structure Design and Complete Installation Guidance

Application:	Automotive Industry, Metal Fabrication Industry
Control Mode:	Continuous Path Control
Degrees of Freedom:	3-Axis

Overview & Basic Info

Model NO.

truss

Drive Mode

Servo Motor + Reducer

Type

Gantry Robot

Payload Capacity

20 Kg

Repeat Positioning Accuracy

+0.05 mm

X-Axis Speed

1.5 M/S

Z-Axis Speed

0.8 M/S

End Gripper

Pneumatic 2-Finger/3-Finger Gripper

Control System

PLC + Motion Control Card

Certification

CE Compliant

Transport Package

Wooden Case

Origin

China

Product Description

Modular Steel Gantry System

Designed for industrial robots, this system allows for flexible assembly and rapid deployment in automated production lines. It offers robust support for various automated tasks including warehouse picking and industrial manufacturing.

Material: Q235 Steel
Dimensions: Modular 1m x 1m units
Load Capacity: 300kg per module
Surface Finish: Powder-coated

Technical Specification

Parameter	Specification
Product Name	Gantry Truss Loading Robot
Payload	20kg
Repeat Accuracy	±0.05mm
Axes	2/3 Axis
Max Speed	X:1.5m/s, Z:0.8m/s
Drive	Servo Motor + Reducer
Material	Aluminum Beam + Q235B Column
Control	PLC + Motion Card (CNC Linkage)
Protection	Dust-proof Cover + Safety Light Curtain
Dimension	10m×1m×3m (Customizable)

Our Advantages

✓ Modular design for flexible deployment
✓ Durable and corrosion-resistant finish
✓ High load capacity per structural module
✓ Fully compatible with modern automation lines
✓ Simplified installation and low maintenance
✓ Laser cutting and precision welding

Packaging & Facilities

Production Capacity & Solutions

Specializing in the R&D and production of industrial robots, gantry robots, robot linear guides, and welding positioners. We provide customized automation solutions across various industrial fields including welding, palletizing, metal processing, and logistics.

Frequently Asked Questions

What materials are used for the robot gantry structure?

The system is primarily constructed using high-quality Q235 steel for columns and aluminum alloy profiles for beams to ensure a balance of strength and weight.

What is the maximum payload capacity per module?

Each standard module is designed to support a load capacity of up to 300kg, making it suitable for heavy-duty industrial robot operations.

Is the gantry system compatible with different robot brands?

Yes, our modular steel gantry system is designed to be highly compatible with various industrial robots used in automated production lines.

Can the dimensions of the gantry be customized?

Absolutely. While standard modules are 1m x 1m, the overall dimensions (such as the 10m x 1m x 3m setup) are fully customizable to meet specific site requirements.

What type of maintenance is required for the surface finish?

The components are powder-coated for high durability and corrosion resistance, requiring minimal maintenance even in demanding industrial environments.

How is the equipment protected during international shipping?

We use fumigated wooden cases and secure foam padding on pallets to ensure all components are fully protected during transit.
